SURFACE BARRIER
Surface Barrier are those barriers which is mount on the surface of a road.there are several type of surface barrier Surface Mount Road Blocker Surface Mount Road Blocker Provides a High Level of SecurityAgainst Unauthorised vehicle access.the Surface Mount Barriers Like Road Blocker are designed to provide a High Speed Deployment for secure installation from Vichele Attack.
Technical Specification:
- Control Unit:Microcontroller
- Integration:Capable of Integration with the overall architecture of Surveillance & Access Control System
- Drive Unit Electro:Hydraulic/Electromechanical
- Electric motor capacity:Approx.3.0,3 phase,50/60 Hz
- Wall thickness of structural components:6 mm
- Blocking height above road level:750mm
- Impact or Crash Rate:Can Stop15,000 pound truck travelling at 50Km/h Speed
- Wheel load:100 Ton vertically
- Operating time Raising:4-5 sec.,lowering 3-4 sec.
- Surface protection:Tri-Protected layers in accordance with special coating (zinc plus 2 layers of plastic coating).
- Hydraulic:Castrol EP 68 HYSPIN
- Operating Temperature:-25ºC to +70ºC
- Power failure/emergency:operation By integrated hydraulic hand pump
- Material of Construction:Engineered Structural Steel for high-impact.
FEATURES
- No Foundation Requirment
- On Site Assembly
- High Quality Material Used
- Manual Opertion Facility
- Hydralic Construction
BENEFITS
- Can Be Used On Any Terrain
- Fastest Installation
- Operation In Power Failure Condition
- Durability
